RF-star Introduces New CC1352P7 Module:Dual-Band + Multiprotocol + Long-Range
RF-star, a leading wireless module maker, launches a new versatile module over Texas Instrument’s SoC - CC1352P7. The product named as RF-TI1352P2 features dual-band radio (Sub-1 GHz and 2.4 GHz) , concurrent multiple protocols and long-range communication. Specifications RF-TI1352P2 is a new item in RF-star’s CC1352 series. Built upon an Arm® Cortex® M4F main processor the CC1352P7 SoC itself was optimized for low-power wireless communication and advanced sensing scenarios such as grid infrastructure, building automation, retail automation, personal electronics, and medical applications. RF-TI1352P2Specifications Chipset CC1352P7 Supply Power Voltage 1.8 V ~ 3.8 V, 3.3 V is recommended Frequency 800 MHz ~ 928 MHz, 2402 MHz ~ 2480 MHz Maximum Transmit Power +20.0 dBm (Sub-1GHz) +5.0 dBm (2.4 GHz) Receiving Sensitivity -121 dBm @ Sub-1 GHz (Long-range Mode) -110 dBm @ Sub-1 GHz (50 kbps) -104 dBm @ Sub-1 GHz (100 kbps) -97 dBm @ Bluetooth 5.0 (1 Mbps) -92 dBm @ Bluetooth 5.0 (2 Mbps) -104 dBm @ Bluetooth 5.0 (125 kbps LE Coded PHY) GPIO 24 Flash 704 KB ROM 256 KB SRAM 88 KB Power Consumption RX current: 5.4 mA, 868 MHz 6.4 mA, 2.4 GHz TX current: 64 mA @ +20 dBm, 915 MHz 24.9 mA @ +14 dBm, 868 MHz MCU 48 MHz (CoreMark): 2.9 mA (60 μA/MHz) Sensor Controller: 30.1 μA @ low power mode, 2 MHz, running infinite loop 808 μA @ active mode, 24 MHz, running infinite loop Standby mode: 0.85 µA Sleep Mode: 150 nA Supported Protocols Thread, Zigbee®, Matter, Bluetooth® 5.2 Low Energy, IEEE 802.15.4g, IPv6-enabled smart objects, (6LoWPAN), MIOTY®, Wireless M-Bus, Wi-SUN®, KNX RF, Amazon Sidewalk, proprietary systems, SimpleLink™ TI 15.4-Stack (Sub-1 GHz) Crystal 48 MHz, 32.768 kHz Package SMT packaging (1.27-mm half-hole pitch stamp stick) Dimension 26.5 mm × 16.9 mm × 2.1 mm Type of Antenna Half-hole ANT interface, IPEX connector Operating Temperature -40 ℃ ~ +85 ℃ Storage Temperature -40 ℃ ~ +125 ℃ For the detailed specifications, please download RF-TI1352P2 hardware datasheet here. 1. Rich Computing Resources The module is with a high-performance 48 MHz ARM Cortex-M4F processor, a 704 KB Flash memory and a 256KB ROM. The resources are rich enough to run various IoT applications, even for demanding Matter networking scenarios. 2. Concurrent Multiprotocol: BLE, ZigBee, Matter, Wi-SUN, etc As a multi-protocol module, RF-TI1352P2 supports Zigbee®, Thread, Matter, Bluetooth® 5.2 Low Energy, IEEE 802.15.4g, 6LoWPAN, MIOTY®, Wi-SUN, proprietary systems. The protocols can run concurrently with a DMM (dynamic multiprotocol manager) which can make real-time switching among separate protocols in the chip, enabling you to design simple, cost-effective and still versatile solutions. 3. Dual-Band Radio: Sub 1GHz & 2.4 GHz RF-star’s dual-band module RF-TI1352P2 provides maximum flexibility in network communication. In addition to the 2.4GHz band that accommodates Bluetooth Low Energy, ZigBee, Thread and more protocols...
