The CC2640R2L recently launched by TI (Texas Instruments) is a 2.4 GHz wireless microcontroller (MCU) supporting Bluetooth® 5.1 features: LE Coded PHYs (Long Range), LE 2-Mbit PHY (High Speed), Advertising Extensions, Multiple Advertisement Sets, as well as backwards compatibility and support for key features from the Bluetooth® 5.0 and earlier Low Energy specifications. CC2640R2L and CC2640R2F both use a single-core software development kit (SDK) and a rich tool set to share a common and easy-to-use development environment. The low-power wireless microcontrollers CC2640R2F and CC2640R2L, both launched by Texas Instruments, can transmit and receive radio frequency signals with a larger range. CC2640R2L, as a low-cost version of CC2640R2F, is lower in price. Judging from the Bluetooth protocol supported by the chip, CC2640R2F supports BLE 5.0 protocol, and CC2640R2L supports BLE 5.1 protocol. CC2640R2L can use AOA/AOD for indoor positioning, which is very suitable for improving the performance of Internet of Things (IoT) applications. In terms of cores, both CC2640R2L and CC2640R2F are the same: 48 MHz ARM® Cortex®-M3 cores, and they both have 275 KB non-volatile memory, including 128 KB in-system programmable flash, up to 28 KB system SRAM, of which 20 KB is ultra-low leakage SRAM. Compared with CC2640R2F, CC2640R2L does not have a Sensor Controller Engine, so the cost of CC2640R2L is lower and it is more suitable for the application scenarios of basic transparent transmission function. CC2640R2L: Microcontroller Powerful Arm® Cortex® -M3 Up to 48 MHz clock speed 275 KB of nonvolatile memory including 128 KB of in-system programmable flash Up to 28 KB of system SRAM, of which 20 KB is ultra-low leakage SRAM 8 KB of SRAM for cache or system RAM use Supports over-the-air upgrade (OTA) RoHS-compliant packages 5 mm × 5 mm RHB VQFN32 (15 GPIOs) 7 mm × 7 mm RGZ VQFN48 (31 GPIOs) Peripherals All digital peripheral pins can be routed to any GPIO Four general-purpose timer modules (eight 16 bit or four 32 bit timers, PWM each) UART, IIC, and IIS Real-time clock (RTC) AES-128 security module Integrated temperature sensor Low power Wide supply voltage range Normal operation: 1.8 V to 3.8 V External regulator mode: 1.7 V to 1.95 V RF section 2.4-GHz RF transceiver compatible with Bluetooth low energy 5.1 and earlier LE specifications Excellent receiver sensitivity (–97 dBm for BLE), selectivity, and blocking performance Programmable output power up to +5 dBm Single-ended or differential RF interface CC2640R2F: Microcontroller Powerful Arm® Cortex® -M3 Up to 48 MHz clock speed 275 KB of nonvolatile memory including 128 KB of in-system Programmable Flash Up to 28 KB of system SRAM, of which 20 KB is ultra-low leakage SRAM 8KB of SRAM for cache or system RAM use Supports over-the-air upgrade (OTA) RoHS-compliant packages 2.7 mm × 2.7 mm YFV DSBGA34 (14 GPIOs) 4 mm × 4 mm RSM VQFN32 (10 GPIOs) 5 mm × 5 mm RHB VQFN32 (15 GPIOs) 7 m...

What can Bluetooth 5.0 do? What kind of Bluetooth 5.0 applications are available in the market? RF-star senior advisor XCODER has the following opinions. The applications of Bluetooth 5.0 are the same as that of Bluetooth 4.x. For the time being, Bluetooth 5.0 can replace the applications of Bluetooth v4.x. Even more, it can replace the original classic Bluetooth SPP transparent transmission applications because of its higher rate. Bluetooth Mesh protocol as a part of the Bluetooth 5.0 has great potential markets in smart home and Bluetooth light control. Many companies are already joined in Bluetooth Mesh smart home market, and finally use smart speakers as the Internet entrance of smart home. The following two paragraphs are from the SIG: “The strategic decision to adopt Bluetooth as the communications platform for our smart home strategy was an obvious choice for us,” said Lijuan Chen, Head of Alibaba A.I. Labs, the department leading consumer AI product development at Alibaba Group. “Bluetooth mesh is a wireless protocol that enables us to meet our customers’ scale, performance, and reliability requirements in the home. Bluetooth is already a proven, trusted, and widely used wireless standard, and we’re confident Bluetooth mesh will be the standard in home and building automation for years to come.” “Bluetooth mesh is one of many fundamental enablers of future IoT markets, allowing for robust, secure, and scalable connectivity across the smart home, commercial building automation, industrial environments, and beyond,” said Stuart Carlaw, Chief Research Officer, ABI Research. “Bluetooth mesh, in conjunction with Bluetooth beacons, can propel these environments towards greater automation, increased sensorization, and enable valuable RTLS services. Nearly 360 million annual Bluetooth Smart Building device shipments are forecasted by 2022.” What are the main Bluetooth 5.0 chips? Some mid-end & low-end Bluetooth chip manufacturers and emerging companies in China Mainland and Taiwan are also actively joining in Bluetooth 5 market. Such as Airoha, Telink, Freqchip, Maxscend, Barrot and Bekin. The biggest drawback of ZigBee is that it cannot communicate with mobile phones. Bluetooth Mesh is an emerging technology that enables real-time interaction between devices and mobile phones, and enterprises are definitely willing to invest in it. The appearance of the SIG leaders and Alibaba in various public occasions is a clear signal to us that new technology means new opportunities.

With the rapid development of indoor positioning technology and the gradual implementation of the related projects, the indoor positioning technology based on Beacon has matured step by step, thus, Bluetooth Beacon is widely used in indoor positioning service. According to the survey data of Markets & Markets, the global indoor location market size to grow from USD 6.1 billion in 2020 to USD 17.0 billion by 2025, at a Compound Annual Growth Rate (CAGR) of 22.5% during the forecast period. The major factors driving the growth of the indoor location market are the increased number of applications powered by beacons and Bluetooth Low Energy (BLE) tags and growing integration of beacons in cameras; and Light Emitting Diode (LED) lightning, Point of Sales (PoS), and digital signage. The proliferation of smartphone connected devices and location-based applications is also expected to drive the market growth. North America is expected to hold the highest share in the global indoor location market, while Asia Pacific (APAC) is expected to grow at the highest CAGR during the forecast period. The region is witnessing significant developments in the market. North America is projected to hold the largest market size during the forecast period. Key factors favoring the growth of the market in North America include the increasing investments in the development of various technologies and application of indoor location solutions. The growing number of indoor location players across regions is expected to drive the market growth further. Asia-Pacific market will play an important role in driving the development of the global market, especially due to the rapid growth of China, India and Southeast Asian countries. In 2018, the market scale of China's indoor positioning was RMB 3.5 billion, an increase of 47.7% compared with 2017, with a compound annual growth rate of 39.3%. Business expansion based on data has become the most popular business model, especially the accumulation of economies of scale, which has gradually reduced the cost of positioning solutions. In particular, the cost advantages of positioning solutions based on Beacon technology have become more prominent, which also brings new opportunities for indoor positioning industry. For more information about this report visit: https://www.marketsandmarkets.com/Market-Reports/indoor-location-market-989.html The positioning accuracy of Beacon is 2 m ~ 3 m, which can basically meet the application needs of factory visitor tracking, indoor navigation of shopping mall, and anti-lost alarm of valuables. This kind of Beacon devices often have very high requirements for battery life. Let’s see how Beacon devices achieve a long battery life as follows. Beacon device has the advantages of ultra-low power consumption and low cost. Achieving better positioning accuracy needs large numbers of Beacon devices deployed in the sites. Most Beacon solutions on the market are used coin cell CR2032, because CR2032 ...

On November 14, 2019, Nordic announced the launch of the first member of the next-generation nRF53 series chip -- nRF5340 high-end multi-protocol system-level chip. The chip to build in the Nordic nRF51 and nRF52 multi-protocol series chips, and at the same time introduced a dual processor hardware architecture, with high performance and low power consumption, extensibility, high heat resistance advantages, can be widely used in smart home, indoor navigation, professional lighting, industrial automation, wearable devices, and other complex Internet applications. Based on the design of the Arm cor-M33 dual-core processor, the nRF5340 integrates high-performance application processors, programmable ultra-low power network processors, and security functions into a low-power multi-protocol SoC. At the same time, the chip also enhances dynamic multi-protocol support, and supports Bluetooth 5.1, low-power Bluetooth, Bluetooth Mesh, Thread, and Zigbee protocols. It can be configured or debugged by smart phones using low-power bluetooth, and interact with Mesh networks. The wireless transmitter is equipped with all Bluetooth 5.1 direction finding functions. The nRF5340 operates in a power supply voltage range of 1.7 to 5.5V, allowing rechargeable batteries and USB power. nRF5340 integrates a new power-optimized multi-protocol 2.4ghz radio with a transmitting current of 3.2ma (0dbm transmitting power, 3V, DC/DC) and a receiving current of 2.6ma (3V, DC/DC). The sleep current was as low as 1.1 A. The nRF5340 launched this time, the main processor Application processor is responsible for the calculation of complex functions and bluetooth protocol stack. It adopts the Arm architecture -m33 under the Arm architecture that has always been used by Nordic, and mounts DSP and floating point functions at the same time, which can be used for third-party development and Application. The kernel runs at up to 128 MHz, supports voltage and frequency regulation, and contains dedicated 1 MB of flash memory and 512 KB of RAM memory, which can meet the needs of the next generation of cutting-edge wearable devices and significantly improve performance over the previous generation of nRF52840. The sub-core Network processor can be used as the computation of additional and uncomplicated content, which also USES Arm corcor-m33, the kernel runs at 64 MHz (238 CoreMark), and is dedicated to 256 KB flash and 64 KB memory. The low power consumption and low duty cycle sensor acquisition during radio operation are optimized. Provides optimal implementation of the 2.4 GHz private protocol and ensures portability from the nRF51 and nRF52 series. The two processors can work independently of each other, connect directly through the IPC, or wake up to each other, but consider their respective protection Settings. In addition, the application processor also integrates security functions such as Arm cryptocell-312 security key storage, providing the highest level of security. It works by h...

IC card is another new information tool after magnetic card, which refers to integrated circuit card. Bus card is a kind of IC card. The common IC card uses RF technology to communicate with IC card reader. According to its structure, IC card can be divided into general memory card, encrypted memory card, CPU card and super smart card. 1. Memory card, whose embedded chip is equivalent to ordinary Serial EEPROM memory, has the advantages of convenient information storage, simple use, low price of IC card, and can replace magnetic card in many occasions. However, because it does not have the function of information security, it can only be used in applications with low security requirements. 2. The logic encryption card and the encryption memory card are embedded with chips, and the control logic is added outside the storage area. Before accessing the storage area, the password needs to be checked. Only the password is correct, can the access operation be carried out. This kind of information has good confidentiality. 3. CPU card, with chip embedded in the card, is equivalent to a special type of single-chip microcomputer, which has not only controller, memory, timing control logic, but also algorithm unit and operating system. Because CPU card has the characteristics of large storage capacity, strong processing capacity, information storage security and so on. It is widely used in the situation where information security requirements are particularly high. 4. Super smart card, which has MPU and memory, keyboard, LCD and power supply, is rare. IC card is divided into contact IC card and non-contact IC card according to the different interface of data exchange with the outside world. The contact IC card can read and write data after the contact of the IC card reading and writing device contacts with the contact of the IC card. The international standard ISO7816 has strict regulations on the mechanical and electrical characteristics of such cards. The contactless IC card has no circuit contact with the IC card equipment, but read and write through the contactless read and write technology, which successfully solves the problem of passive and contactless, and is a major breakthrough in the field of electronic devices. In addition to CPU, logic unit and memory unit, the embedded chip adds RF transceiver circuit. This kind of card is generally used in the automatic toll collection system of public transportation, ferry, subway and other occasions with frequent use, relatively less information and high reliability requirements. At present, the most common contactless IC card in the market is contactless logic encryption card. With its good performance and high cost performance, this kind of IC card has been favored by the majority of users, and has been widely used in public transport, medical treatment, access control and other fields. Because the non-contact logic encryption card chip adopts the stream cipher technology and the key length is not very l...

CC1352R is a multi-protocol Sub-1 GHz and 2.4 GHz dual-band wireless MCU. Compared with CC1352P device we talked about before, CC1352R has no power amplifier. The CC1352R device has very low active RF and micro controller (MCU) current, sleep current less than 1 μA and up to 80KB ram retention capacity protected by parity, which can provide excellent battery life and support long-term operation in energy collection applications relying on small button batteries. The CC1352R device combines a flexible ultra-low power RF transceiver with a powerful 48 MHz Arm ® cortex ® - M4F CPU. Low level RF protocol commands stored in ROM or RAM are processed by a dedicated radio controller (Arm ® cortex ® - M0), thus ensuring ultra-low power consumption and excellent flexibility. The sensor controller with fast wake-up and ultra-low power consumption 2MHz mode is specially designed for sampling, caching and processing of analog and digital sensor data, so MCU system can maximize sleep time and reduce working power consumption. Characteristics of CC1352R Micro controller Powerful 48MHz Arm ® cortex ® - M4F processor EEMBC coremark ® score: 148 352KB programmable flash memory in the system 256KB ROM for protocol and library functions 8KB cache SRAM (also available as general RAM) 80KB ultra-low leakage SRAM. SRAM is protected by parity to ensure highly reliable operation Ultra low power sensor controller with 4KB SRAM Sample, store and process sensor data Independent of system CPU operation Peripheral 4 32-bit or 8 16 Bit Universal timers 12 bit ADC, 200ksps, 8 channels AES 128 bit and 256 bit encrypted accelerometer Low power consumption Wide power supply voltage range: 1.8V to 3.8V Active mode Rx: 5.8ma (3.6V, 868mhz), 6.9ma (3.0V, 2.4GHz) Active mode TX (0dbm): 8.0ma (3.6V, 868mhz), 7.1ma (3.0V, 2.4GHz) Active mode TX (+ 14dbm): 24.9ma (868mhz) Sensor controller, low power consumption mode, 2MHz, operating infinite circulating current: 30.8 μ a Sensor controller, active mode, 24MHz, operating infinite circulating current: 808 μ a Radio part Dual band RF transceiver lower than 1GHz and 2.4GHz compatible with low power Bluetooth 5 and IEEE 802.15.4 phy and MAC standards Programmable output power up to + 14dbm (lower than 1GHz) and + 5dBm (2.4GHz), with temperature compensation The Birth of CC1352R Module Based on the CC1352R multi-protocol Sub-1 GHz and 2.4 GHz dual-band wireless MCU, the Chinese wireless modules manufacturer named RF-star has designed the multi-protocol module RF-TI1352B1 to fit a wide range of applications. RF-TI1352B1 with two bands antenna output will be a perfect choice to simplify your design work. Check the following applications of the CC1352R module, and you may get some good ideas for your IoT design. Applications of CC1352R Module Remote sensor Asset tracking and management Factory automation Wireless medical Energy collection Electronic shelf label (ESL) Home and building automation Wireless alarm and...

The RF-WM-3235B1 module is a Wi-Fi module based on TI CC3235S Wi Fi ® dual-band SoC. It includes 256KB RAM, IoT network security, device identity/key, and MCU level security, such as file system encryption, user IP (MCU Image) encryption, security startup, and debugging security. Simplelink®Wi Fi® CC3235X device family integrates two processors on one chip, including: Arm ®Cortex ® - M4 MCU, 256KB RAM for users and optional 1MB executable flash memory. To run all the network processors of Wi Fi and Internet logic layer, the ROM based subsystem completely reduces the load of host MCU, including a n 802.11a/b/g/n dual band 2.4GHz and 5GHz radio, baseband and and MAC with powerful hardware encryption engine. The RF-WM-3235B1 module of RF-star can directly replace the original CC3235mods CC3235modsf. Major New Features included: Lower power consumption and larger coverage Improved fast scanning With FIPS 140-2 level 1 certification Up to 16 safety sockets can be used at the same time Certificate enrollment request (CSR) Online Certificate Status Protocol (OCSP) Power saving features of IOT certified by Wi Fi ® Alliance (such as DMS, proxy ARP, etc.) No host mode to reduce the transport load of template package Support dual band 2.4GHz and 5GHz Multi layer security features to help developers protect identity information, data and software IP Low power mode for battery powered applications Industrial temperature range: - 40 ° C to 85 ° C Arm ® cortex ® - M4 core, operating frequency 80MHz 27 I / O pins with flexible multiplexing option Main Application: Smart home appliances Smart socket Video monitoring, video doorbell and wireless camera Building safety system and electronic lock, equipment Asset tracking Factory automation Medical and health equipment Basic equipment of power grid The First Dual-band CC3235S Wi-Fi Module is available for your projects. If you are interested in the WiFi modules, please visit our official website www.rfstariot.com or contact us at info@szrfstar.com. We are always with you!

On July 1, 2019, the long-awaited regulations of Shanghai Municipality on the management of domestic waste was officially implemented, and "waste classification" was incorporated into the legal framework in China. By the end of 2020, the 46 key cities in the pilot area will have basically completed the waste classification and treatment system, and by 2025, the cities at prefecture level and above will have basically completed the waste classification and treatment system. Garbage classification will become a major issue in the health management of major cities in China. In the face of increasingly standardized garbage classification management, effective garbage classification solutions are urgently needed in the market to meet the huge garbage management needs in the future. Garbage classification is a whole chain link, which involves classified delivery, classified collection, classified transportation and classified disposal. There is no link to be missed. Garbage classification is closely related to everyone's daily life, while China has a population of 1.4 billion. The huge amount of garbage means that a huge number of garbage cans are needed for classification and transportation. In the waste classification system, the Internet of things industry is quietly playing a role. The application of the Internet of things enables the intelligent garbage sorting and recycling function to accurately classify, analyze, track and process all kinds of garbage. The traditional grid waste management mainly relies on human cost, which has the problems of high timeliness cost, low problem disposal efficiency and weak construction overall planning mode. The standardized waste classification is in urgent need of supporting waste classification solutions. At this time, lorawan low-power Internet of things based on Lora technology is the most suitable for smart waste classification applications. The solution applied to garbage classification has its special requirements: large amount of connection, low communication frequency, low power consumption, complex coverage environment, high-cost sensitivity. The RF-AL42UH module based on Lora technology and ASR6501 is particularly suitable for waste classification solutions. The garbage can be equipped with a light sensor to monitor whether the capacity of the garbage can is full in real time. A smoke alarm can be installed to monitor the ignition of the garbage can. Sensors send data to Lora terminals or modules. Lora communication is transmitted to Lora gateway thousands of meters away through low-power Lora network. The gateway then transmits the data to the cloud. The cloud reanalyzes the sensor data. Garbage managers can more intuitively understand the filling status of each garbage can in their jurisdiction, and plan the best recycling route for clean vehicles. RF-AL42UH module based on Lora technology has a wide application prospect in garbage classification with excellent performance and flexible networking f...

The initial technology maturity curve for iot development is only based on an increase in the number of deployed and potential sensors. Today, we can look to the future and explore some important success factors. Future trends in the Internet of things, including IoT applications, will bring economic benefits to end users. There is also a trend towards longer battery life, lasting for years. In any wireless iot monitoring system, data transmission consumes power. Therefore, the perception and processing take place at the edge nodes through intelligent partitioning, and the amount of data is reduced (in a more sporadic or shorter period) through local decisions, thus bringing significant added value to the iot system. Finally, the key element of the future is the ability to operate safely and reliably. Therefore, for successful iot systems, the focus of iot design will shift to key performance indicators such as trusted sensors and system uptime. Analysts estimate that low - cost development systems are currently in the Peak of expectation inflation. In the next two to five years, differentiated or specialized high - precision sensors and analog signal chains will become the mainstream and truly push the Internet of things market into the future. Importance of Good Data A key process in iot systems is the conversion of analog signals into digital signals. Simply put, the better the transformation,the more useful the data. Silicon technology innovates to transform and interpret the world around it, bridging the real and digital worlds through detection, measurement, interpretation, and connectivity. The most effective iot deployment is the ability to use this data to determine change. And best change is the biggest value for end customer, such as higher efficiency and higher security, such as in factories, machine learning is not only able to identify when may need to machines for predictive maintenance in the future, but also can identify the details and reach a higher level of recognition, to determine what action to take (for example, to identify specific ball bearing in motor wear). Therefore, the first stage of any iot system is to detect, measure, and then convert real-time signals into analytical data. How well this stage is completed will lay the foundation for future success. If the wrong information data is entered, the results obtained from any iot analysis cloud platform will also be wrong. Therefore, the most successful iot systems have to have measurement and reporting levels that other systems cannot. This needs to improve measurement and reporting makes good hardware essential. A recent Gartner report said the same. Report that they are low cost iot development look fast into the bubble period of disillusionment (trough of disillusionment. This may be due to the plethora of low-cost development platforms available. But I think it's more likely that we're focusing on more challenging iot applications that have more real economic valu...
